Ask an Architect: Insulation

Insulation

English / 日本語

From December to February, Tokyo apartments are often colder inside than outside. After braving another winter in sub-igloo comfort, we decided to ask someone in the know where exactly the insulation’s at. The following queries were floated to Néojaponisme’s resident architectural adviser Ashizawa Keiji, who has gracefully explained why Japanese residences do not fare so well in Japan’s seasonal extremes.

Why is there so little insulation in Tokyo homes? And why is central heating not used?

First of all, you can’t say that houses in Japan don’t take heating into consideration. The main actor for temperature control in Japanese living spaces is local heating (partial heating), as symbolized by the kotatsu — the heated table that occupies the cha no ma or living area in so many houses even today.

When I think back to my childhood, I remember that everything in the house outside of the kotatsu during winter was almost as cold as outside. So no one wants to ever leave the kotatsu. We would decide by rock-paper-scissors who had to go get the mikan from the entry hall. The entry hall was as cold as a refrigerator, so we used it to store things like mikan. The corridors and bedrooms (if you weren’t under a futon) were so cold that you could see your breath. So, it was really important to warm yourself up in the bath. And it was really hard to get out of bed in the morning.

A greater awareness of insulation began during to the oil shock of 1973. An idea formed that one could heat the entire home through insulation. When people did the math, they realized that the old way of doing things — only heating up an uninsulated six-tatami room full of cracks and openings — was not energy efficient. Therefore you needed to increase the efficacy of insulation and make more airtight construction. But this then led to “shock houses.” The so-called shock house was a house that caused health problems such as allergies or atopy due to the emission of synthetic chemical materials used in construction. This is why specialized alarms are required in residences constructed today. Every room must have an air vent, and the ventilation fan is left on 24 hours a day. Some claim that this makes the house colder, leading many people to shut off the ventilation during the frigid depths of winter, even if they are aware of the shock house problem.

Is there any desire (either by architects, developers, or dwellers) for more insulation or other uses of heating in modern homes?

High levels of thermal insulation or air sealing are part of many house builders’ sales pitch, and paying attention to insulation is gradually becoming commonplace. I should add, however, that some contractors do remain skeptical…

Although the rules are not set as clearly as in Europe or the United States (due to the regulations of the Government Housing Loan Corporation), builders often publicize and reference the volume of insulation in the roof walls and floor. The idea of localized heating is therefore gradually becoming a thing of the past. Now, even cheap rental apartments have air conditioning units [note: Japanese AC units normally include both heaters and coolers] installed, and it has become a standard custom to heat the entire room.

While there are many different kinds of insulation, the most commonly used one is fiberglass, which is extremely inexpensive. Leaving out insulation is therefore not a particularly clever way to save on construction expenses. Of course, there are builders who ignore insulation in their designs. Houses with large openings and houses with extremely simple construction and thin walls — where the delineation between inside and outside is only marked by spraying concrete — are cold in the winter and hot in the summer.

I once heard a story that, when a certain European country was refurbishing its embassy in Japan, the construction fee was over budget, so the European architect requested a Japanese architect to come up with a cost savings plan. When the European architect saw that one of the suggestions was to “leave out insulation,” he was quite surprised and thought it was a joke! This story happened just a few years ago.

How does the situation in Tokyo compare to other parts of Japan?

Yoshida Kenkō wrote in the Tsurezuregusa that when building a house, one should focus on the summer. This has become fundamental to dwellings in many regions of Japan, meaning that the emphasis is on keeping summer as cool as possible. Only in Hokkaido is there such a thing as the Law on Cold Residences, and the Government Housing Loan Corporation gives financial assistance to homes protected against the cold. They say that people from Hokkaido catch colds when they come to Tokyo, because they traditionally live in houses insulated and warmed through central heating.

Do more expensive homes in Tokyo have central heating/cooling?

There are cases in the past where they put central heating into luxury apartments or homes, but I think it’d be very rare now to see that. They use central heating as a general rule in Hokkaido though.

If my current apartment has insulation, why is it so cold in the winter? Is it just because it was built for summer?

It’s probably that the windows are only single-layer glass, which lets cold air pass in and out. Rental apartments rarely use “pair glass” (glass with insulating properties.) The idea is that you should make the apartment tolerable in the summer, and cost-wise, this is a very convenient strategy for the managers.

Which is warmer in winter: wooden structures (アパート) or concrete structures (マンション)?

That’s a tough question. New apartments are clearly better than old apartments. I have lived in both an old concrete apartment and a old wooden apartment, and both were super cold in winter and fiercely hot in summer. The wooden apartment, however, was nicer at night, because the concrete would store the heat, making you need to use an air conditioning unit.

東京の家は真冬になると家の中が外よりも寒くなる時がよくある。今年も例に漏れずイグルーほど断熱性のないアパートで冬を過ごした我々は、「日本の家に断熱材は存在するのか?」と詳しい人に聞きたくなった。この質問に答えを出してくれる人は、建築家の芦沢啓治さんが浮かび、季節に極端に対応しない日本の家の事情について説明して頂きました。

なぜ東京の住宅では断熱材をあまり使用していないのですか?また、なぜセントラルヒーティングを導入していないのでしょうか?

そもそも日本には、暖房を意識した家はなかったと言われています。 いまだに多くの家庭のリビング、あるいは茶の間を占領するこたつに象徴されるように、局所暖房(部分的な暖房)が日本の住居において主役でした。

僕の幼少時代を思い出してみても、こたつの中以外は、ほとんど外のように寒かった記憶があります。だから、みなこたつから出れなってしまう。玄関に置かれたみかんをとりにいくのをジャンケンできめていました。玄関はまるで冷蔵庫のように寒かったので、みかん程度のものであれば貯蔵庫として使っていました。廊下はもちろん、寝室も布団の中以外は吐く息が白くなる程でした。だから、お風呂で体をしっかり暖めることが重要だったともいえます。 さらに、朝は布団の中からなかなか出れなくなるわけです。

断熱について意識が向かうようになったのは、1973年のオイルショックが引きがねになったといわれています。断熱することによって、家全体を暖めるという発想がでてきたわけですが、いままでの隙間だらけで、断熱されていない6畳の部屋を暖めていたときよりも、結局のところ省エネではなかったという統計がでています。そこでさらに断熱材の性能を上げ、気密を上げることが 必要となり、こんどはシックハウスの原因となってしまいました。シックハウスとは、建材にふくまれた化学物質が家の中に放出されることによってアトピーやアレルギーなどの体の不調をおこしてしまう家のことです。よって現在つくられている住宅は24時間喚起が義務付けられています。すべての部屋に換気口がもうけられ、24時間換気扇をまわしっぱなしにします。これが寒いというクレームがあるのですが、シックハウスの問題を知りながらも真冬の時期は、切ってしまう人もおおいようです。

新しい家にはもっと断熱材を使用して欲しい、他のヒーティング方法を取り入れて欲しいという希望はありますか(建築家、ディベロッパー、入居者から)?

上の文章でもかきましたが、高断熱、高気密というのは多くのハウスメーカーの売り文句であり、断熱について気をつかうということは、常識になりつつあります。 建築家は懐疑的な人もいますが・・・。

ヨーロッパや、アメリカ合衆国のようにルールが明確にきまっているわけではありませんが、 住宅金融公庫基準という形で、屋根、壁、床の部位における断熱量が公表され、参考にするケースが多いです。そして局所暖房という考え方は過去のものとなりつつあります。いまや、安い賃貸アパートでもエアコンが常備され、部屋全体をあたためるのが常識となりつつあります。

断熱材にはいろいろな種類がありますが、一般的によく使われる断熱材はグラスウールと呼ばれるもので、非常に安価なものです。よって、建築コストを抑えるために断熱材を抜くということはさほど賢い方法ではありません。もちろん建築家の中には、デザインのためにあえて、断熱については無視をしている人もいなくはありません。開口部が大きな家、 非常にシンプルな構造、薄い壁、コンクリート打ち放しだけで内外を仕切っている家は、冬寒くまた夏、暑いです。

そういえば、こんな話を聞いたことがあります。ヨーロッパのある国が日本に大使館をリニューアルする際に、工事費があわなかったので、ヨーロッパの建築家が日本のローカルアーキテクトに減額案を提示するようにとお願いしました。いくつかの減額の中で「断熱材をやめる。」というものがあって、ヨーロッパの建築家はあまりに驚き冗談かと思ったようです。ほんの数年前の話です。

東京の状況は、国内のその他の地域と比べてどうでしょうか?

家の作りようは夏を旨とすべしと吉田兼好が徒然草で記しており、これまでの日本の多くの地域において住居の基本になっているようです。夏をいかに涼しく過ごすかということに主眼を置くということです。北海道だけは、古くから「寒住法」というものがあり、防寒住宅に公庫(住宅金融公庫)が融資支援をしています。北海道の人が東京に来ると風邪をひくというのは、彼らが伝統的に、断熱やセントラルヒーティングによって暖められた家に住んでいるということを物語ります。

東京でも、高級な住宅ではセントラルヒーティング/クーリングを使用していますか?

むかしの高級アパートや、家にはたしかにセントラルヒーティングをいれているケースはあるようですが、現在では稀だと思われます。北海道では一般的にセントラルヒーティングを使っているようです。

私が住んでいるアパートに断熱材を使っていたとして、なぜ冬はとても寒いのでしょうか?夏に適した構造に建てられたのでしょうか?

寒いですか。ガラスはシングルガラスですよね。そこから冷気ははいってきます。賃貸マンションでガラスがペア(断熱性能をもつガラス)になっているものは、非常に稀です。夏をしのげればいいという考え方は、賃貸アパートを建てるうえでは、コスト的に、つまり経営者にとっては非常に便利なコンセプトです。

どちらが暖かいですか: 木造建築 (アパート) または コンクリート (マンション)?

これは難しい質問ですが、ひとついえるのは、築年数の古いアパートと、新築のアパートではあきらかに新築のほうが暖かいと考えられると思います。私も、古いコンクリートマンション、古い木造アパートとも住んでいましたが、どちらも非常に寒いです。では夏はというと、やはりどちらも猛烈に暑かったですね。ただし、夜は木造のアパートのほうが過ごしやすい。なぜなら、コンクリートは蓄熱してしまうので、夏場は、クーラーなしでいられないわけです。
